50L capacity |
2 layers of heating for quick melt glue |
Drawer-type structure design for easy maintenance |
high temperature 400° Teflon treatment layer to prevent glue carbonization |
Xinjie operating system, one-click access to various parameters with free switching between Chinese and English
Single and double pumps optional, high temperature 260° hose
Jundingda Machinery high quality Paper Label Sticker Glue Machine configuration is as follows:
Main Technical Parameters |
Specifications |
Application Type |
Hot melt glue |
Glue Tank Volume |
50L |
Glue Outlet |
2-way (1-way reflux) |
Gear Metering Pump |
20cc (1 set of double-layer metering pump), Zhaochuan Group |
Maximum Glue Supply |
72KG/H (1 set of gear pump) |
Melting Speed |
40kg/h |
Maximum Temperature |
240°C |
Control Method |
PLC temperature control system |
Maximum Motor Rotation Speed |
70rpm (1 set of 400W motor), Variable frequency speed motor, Yuxin motor |
Power Supply |
AC-380V, 7.5kW |
Melt Tank Size |
520 x 260 x 1050 mm |
Speed Regulation Method |
Frequency conversion speed regulation drives the glue pump to control glue output |
Frequency Converter |
750W (Tai'an) |
Rubber Hoses |
2 hoses, 3 meters and 3.5 meters |
The Paper Label Sticker Glue Machine can be connected to an external encoder or analog quantity to automatically track the glue volume, automatically schedule the machine to start and stop, display the glue volume on the computer screen, and automatically alarm and shut down when over-temperature failure occurs. With glue replenishment function, the probe detects the glue position and automatically replenishes it.
1, Xinjie or Siemens PLC operating system, English and Chinese operation, automatic switching function, automatic tracking of glue quantity
2, capacity 50L, melting speed 45kg per hour, AC380V power 9.5kw, upper and lower 2 layers of independent heating.
3, metering pump 2*5.4cc*2 sets 2*20cc, sensor type k or pt100 (other metering pumps and sensors are acceptable)
4, glue supply method: high precision metering pump glue supply, servo and frequency conversion drive optional, glue outlet 2-4, reflux 2-4
5, can be connected to 2-4 tubes 2-4 guns, (glue gun optional: reverse suction scraper gun, glue gun, spiral spray gun, fiber spray gun)
6, suitable for air filter, non-woven fabric, opp film, automotive interior and exterior decoration, hygiene products, medical industry and other products spraying adhesive compound.
