Ensure a Level Installation Ground: The surface where the machine will be installed must be flat and level.
Power Supply Requirements: The power supply line must match the machine’s power requirements and should be securely fixed in place.
Proper Grounding: The Filter Mchine must be properly grounded. Connect the ground wire to the machine’s foot mounting bolt. Do not use the neutral wire as a ground wire.
Unobstructed Access: Ensure that the route to the installation site is clear. Arrange for a forklift with a capacity of over two tons to handle the machine’s transportation.
Installation Space: Maintain a minimum distance of one meter from the left and right sides of the machine to any walls, and at least 1.5 meters in front and behind the machine.
Securing the Machine: Anchor bolts should be used to fix the machine in place. Alternatively, place the machine on rubber pads to prevent movement.
Electrical Specifications: The machine operates on a 380V/50Hz power supply. Install an appropriate safety device and switch in front of the machine’s external power supply connection.
